Part_No Configuration Package Vds(V) Vgs(V) Vth(V) Id(A) Rds(on)/Typ(mΩ) Qg/Typ(nC) Application Cross Reference Download
25℃ 100℃ Vgs=10v Vgs=4.5v Vgs=1.8v Vgs=1.5V
S40N08M Single-N TO-252 40 ±20 78 49 BMS
S40N09R Single-N TO-220/TO-263 40 ±20 90 57 BMS
S40N12M Single-N TO-252 40 ±20 120 76 BMS
S40N14R Single-N TO-220/TO-263 40 ±20 140 88 BMS
S45N17R Single-N TO-220/TO-263 45 ±25 170 107 BMS
S60N10M Single-N TO-252 60 ±25 100 63 BMS
S60N12R Single-N TO-220/TO-263 60 ±25 120 76 BMS
S60N15R Single-N TO-220/TO-263 60 ±25 155 98 BMS
S60N18R Single-N TO-220/TO-263 60 ±25 180 114 BMS
S65N07M Single-N TO-252 65 ±25 71 45 BMS
S68N08ZR Single-N TO-220/TO-263 68 ±25 80 50 E-bike
S68N08R Single-N TO-220/TO-263 68 ±25 82 52 E-bike
S70N06R Single-N TO-220/TO-263 70 ±25 57 36 SMPS
S70N08ZR Single-N TO-220/TO-263 70 ±25 80 50 E-bike
S70N08R Single-N TO-220/TO-263 70 ±25 90 57 E-bike
S80N08R Single-N TO-220/TO-263 80 ±25 84 53 E-bike
S80N10R Single-N TO-220/TO-263 80 ±25 100 63 E-bike
S80N18R Single-N TO-220/TO-263 80 ±25 180 113 E-bike
S80N22T Single-N TO-247 80 ±25 196 124 E-bike
S85N16R Single-N TO-220/TO-263 85 ±20 153 96 E-bike
页次:1/2页 总记录33  1  2
